Austin Hughes InfraSolutionX - Smoke detector + 1m cord

1. AUSTIN HUGHES Temperature + humidity 2-in-1 sensor + 2m cord
2. AUSTIN HUGHES Temperature + humidity 2-in-1 sensor + 4m cord

• One sensor for temperature & humidity
• Low profile and light weight design with a magnetic base for easy affixing to rack
• Part no. :
• IG-TH01-2M with 2M cord
• IG-TH01-4M with 4M cord

3. AUSTIN HUGHES Smoke detector + 1m cord
4. AUSTIN HUGHES Smoke detector + 3m cord

• Safely operated smoke detection
• Part no. :
• IG-S01-1M with 1M cord
• IG-S01-3M with 3M cord

5. AUSTIN HUGHES Shock Sensor + 1m cord
6. AUSTIN HUGHES Shock Sensor + 3m cord

• Alert the physical vibration on the rack
• Part no. :
• IG-V01-1M with 1M cord
• IG-V01-3M with 3M cord

7. AUSTIN HUGHES 5m rope-type water sensor + IP68 cable joint + 3m cat 6 Cable

• Fluid leakage detection
• 5M rope round the rack bottom to detect any fluid flowing to the rack area
• IP65 cable joint connectors provided
• Part no. :
• IG-W01-3M with 3M cord

8. AUSTIN HUGHES Adhesive Inductive Sensor + 2m cord, pair
9. AUSTIN HUGHES Adhesive Inductive Sensor + 4m cord, pair

• Inductive Door Sensor, pair ( S-DSI )
• light weight / adhesive
• easy setup for existing rack retrofit
• no custom cutting required on doors
• mounting bracket bundled

10. AUSTIN HUGHES Mechanical Door Switch + 2m cord, pair
11. AUSTIN HUGHES Mechanical Door Switch + 4m cord, pair

• Mechanical Door Sensor, pair ( S-DSW )
• low cost / precise
• cost efficient integration to new rack
• custom cutting required on doors

12. AUSTIN HUGHES LED Light Bar, magnetic base + 2m cord
13. AUSTIN HUGHES LED Light Bar, magnetic base + 3m cord

• Auto ON / OFF by door sensor detection
• Manual ON / OFF by software remote
• Magnetic base for easy affixing to rack
• Dimension ( W x D x H ) : 20 x 300 x 12 mm
• Part no. :
• CLB-IX-002 with 2M cord
• CLB-IX-003 with 3M cord

14. AUSTIN HUGHES Flashing LED Beacon + 1m cord
15. AUSTIN HUGHES Flashing LED Beacon + 3m cord

• Highly visible for alerting user to alarm status
• Part no. :
• IG-FB03-1M with 1M cord
• IG-FB03-3M with 3M cord

Sensor / Peripheral

To maintain optimum operational conditions in data centers, getting instant notification of various environmental fluctuations is vital. InfraSolutionX offers a wide range of sensors for complete environmental monitoring, including temperature, humidity, smoke, shock and water leakage.

Peripherals such as LED light bars and flashing LED beacons, are designed for use with the sensors for a comprehensive local environmental monitoring solution.

Overview

Security

Rack level access security has become critically important for all data centers and server rooms. More and more IT managers have recognized this need and upgraded their racks with smartcard access control.

InfraSolution® X 800 series provides data center managers a complete networked solution with monitoring, control, alarm & reporting. It allows rack access remote management - saving traveling time / costs and hence increases the data center operation efficiency.

Compatibility

Hardware

X-800 handle is designed for the global IT branded rack. Its Universal Mounting Cut-out generally allows easy integration with most third party racks so costly & complicated door customization is not required.

Software

We offer InfraSolution® X Manager for software remote management. Besides, InfraSolution® X also supports SNMP for integration to the existing BMS of data center. Users can use their own platform for a centralized management.

Smartcard

InfraSolution® X caters for the 2 most common Smartcard alternatives - Proximity & MiFARE format. The users can keep using their existing smartcard to apply on the rack access system if their smartcards are in either format as above.

Functionality

Functionality is not limited to rack access management. In addition to rack access control, InfraSolution® X can be further expanded to PDU and environmental management. Users can remotely manage the above devices via the InfraSolution® X Manager .

Expandability

The managing capacity of InfraSolution® X is expandable to a maximum of 3,000 racks. And the InfraSolution® X GUI allows up to 100 concurrent client access to remotely manage the smartcard locking handles.

InfraSolution® X provides the scalable flexibility to the data center projects, especially to the project with several phases.
